17
Burners and nozzles specifications
Installation
For models supplied without a plug, fit a standard plug, suitable
for the load indicated on the rating plate, onto the cable and
connect to a suitable socket. To connect directly to the mains
supply, a double-pole switch with a contact separation of at
least 3 mm suitable for the load and complying with current
standards and regulations, must be fitted between the appliance
and the mains supply outlet. The yellow-green earth wire must
not be interrupted by the switch. The supply cable must be in
such a position that no part of it can reach a temperature of 50
°C above room temperature. For installation above a built-
under oven, the hob and the oven must be connected separately
to the electricity supply both for safety reasons and for easy
removal of the oven if necessary. Do not use adapters or
shunts as they could cause heating or burning. Before
connecting to the power supply, make sure that:
• the limiter valve and the domestic system can withstand
the load from the appliance (see rating plate);
• the supply system is efficiently earthed according to
standards and laws in force;
• the socket or double-pole switch are easily accessible
when the appliance is installed.
Important: the wires in the mains lead are coloured in
accordance with the following code:
Green & Yellow
- Earth
Blue - Neutral
Brown - Live
As the colours of the wires in the mains lead may not
correspond with the coloured markings identifying the terminals
in your plug, proceed as follows:
Connect the Green & Yellow wire to terminal marked “E” or
or coloured Green or Green & Yellow.
Connect the Brown wire to the terminal marked “L” or
coloured Red.
Connect the Blue wire to the terminal marked “N” or
coloured Black.
FAILURE TO OBSERVE THE ACCIDENT-PREVENTION
REGULATIONS RELIEVES THE MANUFACTURER OF
ALL LIABILITY.
Replacing the cable
Use a rubber cable of the type H05RR-F with a suitable cross
section 3 x 1.5 mm².
The yellow-green earth wire must be 2-3 cm longer than the
other wires.
This appliance conforms with the following European
Economic Community directives:
-
73/23/EEC of 19/02/73 (Low Voltage) and subsequent
modifications;
- 89/336/EEC of 03/05/89 (Electromagnetic Compatibility)
and subsequent modifications;
- 90/396/EEC of 29/06/90 (Gas) and subsequent
modifications;
- 93/68/EEC of 22/07/93 and subsequent modifications.
* At 15°C and 1013 mbar-dry gas
Propane G31 H.s. = 50,37 MJ/kg
Butane G30 H.s. = 49,47 MJ/kg
Natural gas G20 H.s. = 37,78 MJ/m 3
ENERGY LABEL
Directive 2002/40/EC on the label of electric ovens
Norm EN 50304
Energy consumption for Natural convection
heating mode: Convection
Declared energy consumption for Forced convection Class
heating mode: Fan assisted
Table 1 Liquid gas Natural gas
BURNER
Diameter
(mm)
Thermal power
kW (H.s.*)
By-pass
1/100
(mm)
Injector
1/100
(mm)
Flow *
g/h
Injector
1/100
(mm)
Flow*
l/h
Nomin. Reduc. G30 G31 G20
C.Rapid 100 3.00 0.7 40 86 218 214 116 286
B. Semi-rapid 75 1.65 0.4 30 64 120 118 96 157
A. Auxiliary 55 1.00 0.3 27 50 73 71 71 95
D. Double flame DC DR (internal) 30 0.90 0.4 30 44 65 64 70 86
D. Double Flame DC DR (external) 130 4.10 1.3 57 70 298 293 110 390
Supply pressure
Nominal
Minimum
Maximum
28-30
20
35
37
25
45 20
17
25
