Often, the setup for Master-Slave
and Standalone operation requires
at the first fixture in the chain be
itialized for this purpose via either
ttings in the control panel or DIP-
th
in
se
switches. Secondarily, the fixtures
that follow may also require a slave
setting. Please consult the
“Operating Instructions” section in
this manual for complete instructions
for this type of setup and
configuration.
Hanging Clamp
Note!
Clamp is sold separately.
nd-Alone/Master/Slave Fixture Linking
1. Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector
of the first fixture.
fixture which will have a (female) 3 pin
consisting of a (male) 3 pin connector. Then,
ounting
R I E N T A T I O N
This fixture may be mounted in any position provided there is adequate room for ventilation.
fixture by loosening both knobs and tilting the fixture. After finding the
desired position, retighten both knobs.
•
•
•
Never mount in places where the fixture will be exposed to rain, high
Sta
2. Connect the end of the cable coming from the first
connector to the input connector of the next fixture
proceed to connect from the output as stated above to the input of the following fixture and so on.
M
O
R I G G I N G
It is important never to obstruct the fan or vents pathway. Mount the
fixture using, a suitable “C” or “O” type clamp. Adjust the angle of the
When selecting installation location, take into consideration lamp
replacement access and routine maintenance.
Safety cables should always be used.
humidity, extreme temperature changes or restricted ventilation.
