Cleveland Range Open Base & Modular Gas Skillet SGM-30-TR - Manual (Page 2)

SECT.
XII
PAGE
8
0707
Litho in U.S.A.
(NOT TO SCALE)
NOTES:
Cleveland Range reserves right of design improvement or modification, as warranted.
Many regional, state and local codes exist and it is the responsibility of the owner and installer to comply with the codes.
Cleveland Range equipment is built to comply with applicable standards for manufacturers. Included among those approval agencies are U.L., NSF, CGA, CSA, ETL and others.
32"
813mm
30"
762mm
SUGGESTED
FLOOR
DRAIN
GRATE
12"
305mm
23 1/2"
597mm
(PAN
SURFACE)
35"
889mm
40"
1016mm
37"
940mm
42"
1067mm
28"
711mm
26"
660mm
4 1/2"
114mm
33 1/2"
851mm
13"
330mm
26"
660mm
15 1/4"
387mm
3 1/2"
89mm
72"
1829mm
(COVER
FULLY
OPEN)
A
B
(PAN SURFACE)
LIP (CENTERED ON SKILLET)
DRAIN
PAN
TD 2
TD 2 &
DRAIN PAN
DOUBLE
PANTRY
FAUCET
TD 2 OUTLET
PIPE DRAIN RECOMMENDED
MINIMUM VALVE SIZE PLUS 1" (26mm)
RECOMMENDED
FLOOR SLOPE
1" (26mm) IN
4’ (1220mm)
P
A
N
I
N
F
U
L
L
T
IL
T
P
O
S
IT
IO
N
1 1/4 NPT (DRAIN PIPE)
D E
SUGGESTED
FLOOR DRAIN
GRATE FOR
TD 2
15"
381mm
28"
711mm
7/16" , 3 HOLES
ON 2 3/4" (70mm) B.C.D.
FLANGED
FOOT DETAIL
(REAR LEGS ONLY )
120 ° 120 °
3 1/2" (89mm)
1" (26mm)
(MAXIMUM
ADJUSTMENT
2" (51mm)
4"
102mm
16 1/2"
419mm
6"
153mm
23"
584mm
6 1/4"
159mm
VOLTS: 120
PHASE: 1
AMPS: 1.8
FREQ: 60 HZ
220/240
1
.83
50 HZ
ELECTRICAL
SUPPLY
(6’ CORD & PLUG)
TYPE: NAT or LP
WATER COLUMN: 4.5 (NAT), 10.5 (LP)
BTU PER CU. FT.: 1000 (NAT), 2500 (LP)
SUPPLY PRESSURE:
5" W.C. MIN (NAT), 11" W.C. MIN (LP)
BTU RATINGS:
SGL-30-TR: 91,000 per hour
SGL-40-TR: 130,000 per hour
SGL-30-TR
440 LBS.
200 KG.
SGL-40-TR
520 LBS.
237 KG
APPROX.
SHIPPING
WEIGHTS GAS SUPPLY
(PIPING 3/4" NPT) CLEARANCE
SPECIFICATIONS
MODEL
SGL-30-TR
SGL-40-TR
A
36"
(915mm)
48"
(1220mm)
DIMENSIONS
B
32"
(812mm)
44"
(1118mm)
C
9"
(229mm)
12 1/8"
(308mm)
D
5"
(127mm)
8"
(203mm)
E
20"
(508mm)
22"
(559mm)
NOTE : NON STANDARD ITEMS ARE SHOWN IN GRAY
MIN. TO COMBUSTABLE
SURFACES:
SIDES: 0, REAR: 6" (153mm)
MIN. TO NON COMBUSTABLE
SURFACES: SIDES & REAR: 0
NOTE: 4 1/2" (115mm) required
on right hand side for faucet
EXTERIOR HINGES
REQUIRED FOR
OPTIONAL TD 2
In 4 oz. servings. Other sizes may be calculated.
30 gallons / 115 Liters ............. 960
40 gallons / 150 Liters ............1280
CAPACITIES
EXTERIOR HINGES
(REQUIRED FOR
OPTIONAL TD 2)
