Shaving With Mini Foil Shaver
Use the narrow mini shaver to shave along con­
toured edges to remove any stubble while creating
a smooth, well-defined beard line.
I Before using the mini shaver, always check it
for wear and damage. If the mini shaver shows
signs of wear or damage, do not use it as injury
may occur. Do not use the mini shaver until it
has been replaced.
D
Pre-trim the contours desired with the
trimmer or precision trimmer without a
comb attachment.
B Put the mini shaver on the Groomer handle.
B Gently press the mini shaver onto the skin
and shave along contoured edges to remove
any stubble. Do not press too hard (fig. 22).
Grooming Nose/Ear Hair
D Be certain the Groomer is in the OFF
position.
B
Remove the trimmer by turning counter­
clockwise and pulling it off the Groomer
handle.
B
Put the nose/ear hair trimmer on the
Groomer handle (1) and turn clockwise (2)
(fig. 23).
Trimming Nose Hair
I Make sure nasal passages are clean.
D Put the nose/ear hair trimmer on the
Groomer handle (1) and turn clockwise (2)
(fig. 23).
B
Turn the Groomer ON and insert the tip
of the attachment into one nostril (fig. 24).
CAUTION: Do Not insert the tip more
than 3/16 in./Smm into your nostril.
B
Slowly move the tip in and out while
turning it around at the same time in order
to remove unwanted hair. For best results,
make sure the side of the tip is firm against
skin.This will reduce the tickling effect that
can occur during trimming of nose hair.
□ Turn off Groomer. Rinse attachment clean
after each use.
Trimming Ear Hair
I Clean outer area of ear and ear canal. Make
sure it is free of wax.
k Nose/ear hair trimmer should be on the
Groomer.
O Turn the Groomer ON and move the tip
softly around the edge of ear to remove hairs
extending beyond the outer ear (fig. 25).
B
Carefully insert the tip into outer ear canal
(fig. 26).
CAUTION: Do not insert the tip further
than 3/16 in./Smm into the ear as this
could cause damage to the eardrum.
B Turn off Groomer. Rinse attachment clean
after each use.
Cleaning
I Clean the attachments after each use.
I Always switch Groomer OFF, unplug
and remove power supply cord from
Groomer before cleaning.
I Do not use compressed air, abrasive cleaning
agents, scourers or liquids such as alcohol,
benzene, bleach or acetone to clean the
Groomer and attachments.
I Never clean, replace or remove Groomer
attachments with motor ON.
► Do not apply pressure to cutters.
I Do not touch cutters with hard objects as this
may damage them.
During Use:
I If cut hairs have accumulated in the comb
area, remove hairs by shaking, blowing or using
cleaning brush provided. Remember to adjust
the trimming length back to your selected set­
ting when you replace the comb on Groomer.
After Each Use:
D Make sure the Groomer is switched OFF
and disconnected from the electrical outlet.
B
Remove any comb or attachment.
B
Blow and/or shake out any hair that may
have accumulated in the comb or attachment.
□ Rinse combs, attachments and appliance
under warm tap water or with the supplied
cleaning brush.
B
Shake excess water from combs and
attachments and allow to air dry thoroughly.
B
Place the attachment back on the Groomer
handle.
Cleaning the Mini Foil Shaver
D Separate the top part of the mini shaver
from its body (fig. 27).
B
Blow and/or shake out any hair that may
have accumulated inside the mini shaver
(fig. 28).
B
Clean the top part of the mini shaver under
warm tap water (fig. 29).
I The shaving foil is very delicate and should not
be handled.
I If foil becomes damaged, do not continue using
the mini shaver. Do not apply pressure to shav­
ing foil.
I Do not clean the foil with the supplied brush,
as this may cause damage.
□ Shake excess water from mini shaver and
allow to air dry thoroughly.
Do not use a towel to dry the mini shaver as
damage to the shaving foil could occur.
Cleaning the Body Shaver
D Pull the shaving unit out of the body shaver
(fig. 30).
B
Blow and/or shake out any hair that may have
accumulated inside the body shaver (fig. 31).
B
Clean the body shaver and shaving unit
under warm tap water (fig 32).
I The shaving foil is very delicate and should not
be handled.
I If foil becomes damaged, do not continue
using the body shaver. Do not apply pressure
to shaving foil.
I Do not clean the foil with the supplied brush,
as this may cause damage.
□ Shake excess water from body shaver and
shaving unit and allow to air dry thoroughly.
Do not use a towel to dry the shaving unit as
damage wuld pcwn
Replacing the Bodygroom Shaver
Shaving Foil Head
► If the shaving unit is worn or damaged, do not
continue using the Bodygroom shaver. Replace
the shaving unit immediately.
► It is recommended that you replace your
shaving unit once a year.
IA worn or damaged shaving unit should only
be replaced with an original Philips Norelco
shaving foil, model BG2000, which is
available on the Philips Norelco website,
www.philips.com/support or call
1-800-243-3050 for assistance.
► The foil is a precision part. Handle with care.
D
Always switch Groomer OFF and remove
Groomer plug from outlet before
replacing shaving unit.
B
Remove the shaving unit head by pulling it off
the appliance.
B
Place the new shaving unit head on the
Groomer by snapping it into place.
You will hear a "click".
After replacing the shaving unit head, check that
the shaving head is firmly attached before using
Groomer
This Groomer has no other user-serviceable
parts. For assistance call 1-800-243-3050.
Storage
I Be sure Groomer is turned OFF. Remove cord
from outlet and Groomer before storing in a
safe, dry location where it will not be crushed,
banged, or subject to damage.
► Store the Groomer and attachments in the
pouch to prevent damage.
I Do not wrap cord around Groomer when
storing.
I Store cord in a safe location where it will not
be cut or damaged.
► Do not place or store Groomer where it can
fall or be pulled into a tub or sink, water or
other liquid while plugged in.
