To Erase All Codes From Motor Unit Memory
To deactivate any unwanted remote, first erase all codes:
Press and hold the “learn” button on motor
unit until the learn indicator light goes out
(approximately 6 seconds). All previous codes
are now erased. Reprogram each remote or
keyless entry you wish to use.
PROGRAMMING
USING THE “LEARN” BUTTON USING THE MULTI-FUNCTION DOOR CONTROL
MODEL CPTX & CPTKX
REMOTE CONTROL
OWNER’S MANUAL
NOTE: The Passport transmitter works with all Chamberlain 315
MHz Security
✚
® rolling code garage door openers and accessories.
NOTE: When using the Passport transmitter with an access
system or gated entry, contact property manager for instructions on
use.
NOTE: If programming a HomeLink ® transmitter for an access
system is required, contact property manager.
To prevent possible SERIOUS INJURY or DEATH from a moving gate
or garage door:
• ALWAYS keep remote controls out of reach of children. NEVER
permit children to operate, or play with remote control transmitters.
• Activate gate or door ONLY when it can be seen clearly, is properly
adjusted, and there are no obstructions to door travel.
• ALWAYS keep gate or garage door in sight until completely closed.
NEVER permit anyone to cross path of moving gate or door.
WARNING
CAUTION WARNING
WARNING
NOTICE: To comply with FCC and or Industry Canada rules (IC), adjustment or modifications of this
receiver and/or transmitter are prohibited, except for changing the code setting or replacing the
battery. THERE ARE NO OTHER USER SERVICEABLE PARTS.
Tested to Comply with FCC Standards FOR HOME OR OFFICE USE. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired operation.
KG 1 3 9 7 5 KG 1 3 9 7 5
1. Press and release the “learn” button on
the motor unit. The learn indicator light
will glow steadily for 30 seconds.
2. Within 30 seconds, press and hold the
button on the hand-held remote that you
wish to operate your garage door.
3. Release the button when the motor unit
lights blink. It has learned the code. If
light bulbs are not installed, two clicks will
be heard.
2 3 1
KG KG
LiftM ast er
LOCK LIGHT
1. Press and hold the button on the
hand-held remote that you wish to operate
your garage door.
2. While holding the remote button, press and
hold the LIGHT button on the
Multi-Function Door Control.
3. Continue holding both buttons while you
press the push bar on the Multi-Function
Door Control (all three buttons are held).
4. Release buttons when the motor unit lights
blink. It has learned the code. If light bulbs
are not installed, two clicks will be heard.
LiftM ast er
LOCK LIGHT
LOCK
LIGHT
2 1
KG
NOTE: Any button can be used with a garage door opener
and/or access control system. However, the property
manager may have restrictions on which buttons
can be used when operating the gate entrance or
access system.
2 3 1
KG KG
The Remote Control Batteries
The lithium batteries should produce power for up to 5 years. To
replace, pry open case with visor clip or screwdriver, as shown
below. Insert batteries positive side up (+).
Dispose of old batteries properly.
©2006, The Chamberlain Group, Inc.
114A3162B All Rights Reserved
CPTK33 & CPTK33PH
Three Button
Remote Control CPTK13 & CPTK13PH
One Button
Remote Control
CPT13 One
Button Remote
Control
To prevent possible SERIOUS INJURY or DEATH:
• NEVER allow small children near batteries.
• If battery is swallowed, immediately notify doctor.
WARNING
CAUTION WARNING
WARNING
CPT23 Two
Button Remote
Control CPT33 Three
Button Remote
Control
CPT43 Four
Button Remote
Control
