381333–122 D 50 Hanover Road, Florham Park, New Jersey 07932–1591 USA
For sales or service call 1 800 800–2726 (ASCO) www.ascopower.com
In Canada: PO Box 1238, 17 Airport Road, Brantford, Ontario, Canada N3T 5L7
telephone 519 758–8450, fax 519 758–0876, for service call 1 888 234–2726 (ASCO) www.asco.ca
Operator’s
Manual
Series 300
Automatic Transfer Switches
G design, 1000 through 3000 amp. sizes
TABLE OF CONTENTS
section
INSTALLATION 1 . . . . . . . . . . . . . . . . . . . . . . . . . .
SEQUENCE OF OPERATION 2 . . . . . . . . . . . . .
TESTING & SERVICE 3 . . . . . . . . . . . . . . . . . . . .
ADJUSTMENTS 4 . . . . . . . . . . . . . . . . . . . . . . . . .
CONTROL FEATURES 5 . . . . . . . . . . . . . . . . . . .
INDEX back cover . . . . . . . . . . . . . . . . . . . . . . . . .
An experienced licensed electrician must install the ATS.
1000, 1200, 1600 amp. sizes
DANGER is used in this manual to warn of high
voltages capable of causing shock, burns, or death.
WARNING is used in this manual to warn
of possible personal injury.
!
CAUTION is used in this manual to warn
of possible equipment damage.
!
Refer to the outline and wiring drawings provided
with ASCO Series 300 ATS for all installation details.
2000 amp. size
