4 12050-00 TDM76I
STEP 3
STEP 4
Winco Inc.
Service Dept.
507-357-6831
Slide the axle (ref. 2) through the holes in the base (ref. 1). Slide one washer
(ref. 14 onto each end of the axle. Lift the base and tongue assembly and slide
the wheels (ref. 3) on the axle. Place the other two washers (ref. 14) on the axle.
Place the cotter pins (ref. 16) through the axle and bend to secure. •
Place the generator on the base and mount using the hardware provided (ref. 9,
11, 12). •
