Winco WL12000HE - Manual (Page 8)

12020-00 8 60706-224
LOAD VS. OUTPUT
Generator
Load
Speed
(RPM)
Frequency
(Hz)
Voltage
None 3690 61.5 125V
Half 3600 60.0 120V
Full 3510 58.5 115V
The speed of the engine was carefully adjusted at
the factory so that the generator produces the proper
voltage and frequency. For normal usage, the speed
setting should not be changed. If the generator
is being run continuously on a very light load, it is
often advisable to lower the operating speed slightly.
Whenever making any speed adjustments check the
unit with a voltmeter or tachometer and be sure the
speed is correct.
Lower voltage may damage both the generator and
any load connected to it. Running the engine at ex-
cessively high speeds results in high voltage, which
may signifi cantly shorten the life of appliances being
used.
Output voltage should be checked periodically to
ensure continued proper operation of the generat-
ing plant and appliances. If the generator is not
equipped with a voltmeter, it can be checked with a
portable meter. Frequency can be checked by using
an electric clock with a sweep second hand. Timed
against a wrist watch or a stop watch, the clock
should be correct within +/- 2 seconds per minute.
CONNECTING THE LOADS
APPLYING THE LOADS
Allow the engine to warm up for two or three minutes
before applying any load. This will allow the engine
to reach normal operating temperature and oil to
circulate throughout the engine. A short warm-up
time will permit the engine to work more effi ciently
when the load is applied and will reduce the wear in
the engine, extending its life.
Receptacles have been provided to allow loads to
be connected to the generator. The loads should
be added one at a time. If a large motor is being
started or multiple motors are being started, they
should be started individually and the largest should
be started fi rst.
CAUTION: EQUIPMENT OVERLOAD
Keep the generator load within the generator and
receptacle nameplate rating. Overloading may
cause damage to the generator and/or the loads .
Most electric tools and appliances will have the volt-
age and amperage requirements on their individual
nameplates. When in doubt consult the manufactur-
er or a local electrician. The nameplate amperage
rating for electric motors can be misleading. See
“Starting Electric Motors” in Unit Capabilities (page
4).
These engine-generator sets are inherently self reg-
ulating based on engine speed. The engine governor
will automatically adjust itself to the load. No harm
to the generator will result if it is operated with no
load connected. Proper utilization of the receptacles
located on the control panel is necessary to prevent
damage to either the receptacles or the generator.
The generator is a limited source of electrical power,
therefore pay special attention to the receptacle and
generator ratings. The nameplate rating can be
obtained through a single receptacle as long as the
receptacle amperage rating is not exceeded.
GROUNDING
All units must be grounded. Drive a 3/4 or 1” copper
pipe or rod into the ground close to the engine-gen-
erator set. The pipe must penetrate moist earth.
Connect an approved ground clamp, to the pipe.
Run a no. 10 Awg wire from clamp to the generator
ground lug on the receptacle panel. Do not connect
to a water pipe or to a ground used by a radio sys-
tem. The engine-generator covered in this manual
is designed for portable use. DO NOT OPERATE
THIS GENERATOR INDOORS. The unit should
be stored in a warm dry location. During a power
outage, move the unit outdoors to a fl at dry location
such as a driveway or sidewalk.
WIRING
Plug your tools such as drills, saws, blowers, sump
pump and other items to be powered directly into
the generator receptacles. Before plugging in all
the tools and cord sets, recheck the rating of the
generator set. Be sure it can handle the intended
load and is compatible with the voltage, phase, and
current ratings. ‘Hard Wiring’ this unit directly into a
temporary construction site electrical system is NOT
A SIMPLE DO-IT-YOURSELF JOB. For your safety
all wiring must be done by a qualifi ed electrician and
conform to the National Electric Code and com-
ply with all state and local codes and regulations.
Check with local authorities before proceeding.
WARNING: PERSONAL DANGER
A fully isolated, double pole double throw manual
transfer switch must be installed any time a genera-
tor is being connected to an existing distribution
system.
