VACUUBRAND MZ 4C User Manual
Page 24
Documents are only to be used and distributed completely and unchanged. It is strictly the users´ responsibility to check
carefully the validity of this document with respect to his product. Manual-no.: 997999 / 24/04/2008
page 24 of 28
☞ Remove union nut at the condenser and remove hose from
the inlet of the condenser.
☞ Pull off old overpressure safety relief device and install new
one.
☞ Connect hose to the inlet of the exhaust waste vapour con-
denser and tighten union nut.
Round bottom flask 500 ml, coated .......................... 638497
O-ring 28 x 2,5 (FPM) ............................................... 3120553
alternatively
O-ring 28 x 2,5 (FEP) ................................................. 638304
at the spherical ground joint of the round bottom flask at the
inlet
Cleaning and assembling components
Overpressure safety relief device ............................. 638821
(at the exhaust waste vapour condenser)
