TruTrak Digitrak Ref - Manual

DigiTrak Quick Reference GPS MODE
When
AP is …
Display
Shows…
To … … Perform the action
Initially
Powered-On Flashing
– – –
Allow Gyro to Center IMPORTANT!
Hold Aircraft Still for approximately 10 seconds as long
as display is flashing
Engage Autopilot
Click to capture and hold present heading
– OR –
Press and Hold Control Stick Button. After 1 second, the
Control-Stick Mode goes into effect (see
←
below).
Disengaged OFF
Manually Center Gyro
With aircraft heading held completely still, press
and hold both
and simultaneously.
(Display will show –| – |– while centering.)
Hold for about ten seconds, and then release both
buttons.
Disengage Autopilot
Click
- OR -
Click Control Stick Button
Modify selected Ground
Track in 1 degree
increments
Click or once per degree
Hand-fly aircraft to a
different direction Press and Hold Control Stick Button. After 1 second, the
Control-Stick Mode is in effect (see
←
below).
Selected
Ground
Track
Enter a constant-rate turn Hold
or for at least 1 sec, then release.
Constant-turn mode is in effect (see
↑
below).
Engaged,
holding a selected
Ground Track
Alternating
ground track
and
– F –
Enter NAV mode
Press and at the same time, then release
(Note: do not hold buttons down more than one sec).
Depending on position relative to course line, autopilot
will steer for an intercept of up to 45 degrees.
Engaged,
in NAV mode
– 0 – Leave NAV mode
Click or to leave NAV mode, OR
Click Control Stick button to disengage, OR
Press and Hold Control Stick Button. After 1 second, the
Control-Stick Mode is in effect (see
←
below).
←
Disengaged,
in Control Stick
Mode
Electronic
DG Capture a new selected
Ground Track
While holding Control Stick Button, hand-fly to desired
Ground Track. Level the wings, then release Control
Stick Button
↑
Engaged,
in Constant-turn
Mode
Electronic
DG
Stop the turn and capture
a new Ground Track to
be held
Click or
