OWNERS MANUAL – i Forks 41
2. Parameter settings
Par. Function
Default
settings
EU US
Settings
01 Calibration and start-up units (and print units) kg lb kg;lb
02 Smallest graduation step for multirange 1 2 0.1/0.2/0.5/1/2/5/10/20/50
03 Biggest graduation step for multirange 2 5 0.1/0.2/0.5/1/2/5/10/20/50
04 Number of divisions for every range 1000 1000 0000 - 9999 divisions
05 Weighing capacity system (full scale) 2500 5000 0-99999
06 Motion tolerance for stable 2 2 off/0.5/1/2/4/8/16/32 grad./sec
07 Filter size 8 8 off; 1-12 (1 light filtering, 12 high filtering)
08 Auto zero range (zero track) 0.5 0.5 off/0.5/1/3 grad./sec
09 Zero range positive (+) 10 10 0-100 % of span
10 Zero range negative (-) 10 10 0-100 % of span
11 Test function (display service mode) basic basic basic/count/res10
12 Power on – automatic zero no no Yes/no
13 Approved / non-approved version no no No/ntep/oiml
14 Sampling quantity 10 10 1/2/5/10/20/50/95
15 Units switch mode active yes yes no/yes
16 Setpoint function 0 0 0 (not used); 1 (gross overload); 2 (net overload); 3
(fill manual tare); 4 (fill auto tare); 5 (gross overload
not authorize to change gross setting); 6 (net overload
not authorize to change net setting); 7(gross overload
delayed); 8 (net overload delayed); 9 (gross overload
delay not authorize to change gross setting); 10 (net
overload delay not authorize to change net setting)
17 Number of wires per loadcell (sence active) 4 4 4/6
18 Gravity value working area 9.812 9.797 9.750-9.850
19 Print format date/time EU US EU (dd/mm/yy);US (mm/dd/yy)
20 Baudrate com1 9600 9600 600/1200/2400/4800/9600/19200
21 Setting com1 8_n_1 8_n_1 8_n_1; 8_n_2; 7_n_1; 7_n_2
24 End character com1 cr cr cr;lf;crlf
25 Protocol com1 5 5 0(PC bi-directional NU); 1(PC Excel format on print
command); 2 (remote display); 3 (printer protocol with
power control); 4 (printer protocol without power
control); 5 (Bluetooth master)
26 Number of linefeeds com1 4 4 0-9
27 Handshake com1 soft soft soft (Xon/Xoff)/hard (CTS)
28 Printout format for com1 and com2 stnd stnd stnd;total;confi
29 Header lines added 0 0 0 - 3
30 Baudrate com2 9600 9600 600/1200/2400/4800/9600/19200
31 Setting com2 8_n_1 8_n_1 8_n_1; 8_n_2; 7_n_1; 7_n_2
34 End character com2 cr cr cr/lf/crlf
35 Protocol com2 0 0 0(PC bi-directional NU); 1(PC Excel format on print
command); 2 (remote display); 3 (printer protocol with
power control); 4 (printer protocol without power
control); 5 (Bluetooth master)
36 Number of linefeeds com2 4 4 0-9
37 Handshake com2 soft soft soft (Xon/Xoff)/hard (CTS)
40 Level sensor no no no/ls nc/ls no/cs fa/cs ra
41 Delay trigger time level sensor 3 3 0 -1 0 sec
43 Compensation factor correction factor 1 1 0.1-10.0
44 Compensation factor X-direction 1 1 0.1-10.0
45 Compensation factor Y-direction 1 1 0.1-10.0
60 Battery used 6 6 6V /12V
61 Low Bat switch-off time 2 2 0 = never off; 1-99 min
62 Auto shut-off time indicator 2 2 0 = never off; 1-99 min
63 Auto shut-off time forks 3 3 0 = never off; 1 = 30min; 2 = 1h; 3 = 2h
64 Sleep time indicator if used 0 0 0 = not used; 1 to 99 min
65 Auto shut-off time backlight 20 20 off/20/40/80/160/320 sec
66 Backlight brightness 100 100 100%/ 75%/ 50%/ 25%/ 0% (off)
67 Low bat switch off time forks 10 10 0 = never off; 1-99 min
68 Buzzer function active off off off/ on (direct); on (2 sec. delay)
80 Digital corner calibration active 0 0 0 (enabled); 1 (disabled)
81 Compensation factor digital corner A 1.000 1.000 Do not change value after digital corner calibration
82 Compensation factor digital corner B 1.000 1.000 Do not change value after digital corner calibration
83 Compensation factor digital corner C 1.000 1.000 Do not change value after digital corner calibration
84 Compensation factor digital corner D 1.000 1.000 Do not change value after digital corner calibration
85 Matching Bluetooth forks Only enter this parameter to establish a complete new
