Anatomy of the stampede 4x4 vxl – Traxxas 67086-1 User Manual
Page 6
6 • STAMPEDE 4x4 VXL
ANATOMY OF THE STAMPEDE 4X4 VXL
Motor
(Velineon 3500)
Spur Gear
Pinion Gear
Rear Bumper
Wheelie Bar
Slipper Clutch
Electronic Speed
Control (VXL-3s)
Battery Compartment
LED Light Pipe
Battery Hold-Down
Battery
Receiver
Box
Antenna
Mount
Front
Suspension Arm
Front
Bumper
Steering
Servo
Shock
(Oil Damper)
Turnbuckle
(Toe Link)
Turnbuckle
(Front Camber
Link)
Turnbuckle
(Rear Camber Link)
Rear Shock
Tower
Traxxas High-Current
Connector
Rear Body Mount
Chassis
Front Body
Mount
Front
Shock Tower
Drive
Shaft
Half Shaft
Rear Suspension
Arm
Half Shaft
Shock Guard
