Anatomy of the 1/16 e-revo – Traxxas 71054-1 User Manual
Page 6
6 • 1/16 E-REVO
ANATOMY OF THE 1/16 E-REVO
Toe Link
Rear Half Shaft
Wing
Transmission
Chassis
Antenna Mount
Front
Suspension Arm
Front
Bumper
Oil Shock
(Damper)
Rear Body
Mount
Hex Hub
Rear
Suspension Arm
Axle Carrier
Pivot Ball
Steering Link
Receiver Box
Steering Servo
Front Body
Mount
Battery Compartment Door
Battery Compartment Vent
Electronic Speed
Control (XL-2.5)
Motor (Titan
®
12T)
Battery Door Release Tab
Rocker
Rocker
Push Rod
Push Rod
Spring Pre-load
Adjuster
Traxxas High-Current
Connector
Light Pipe
