V18-112/V18-212 Tube Guitar Amplifier with Reverb
10
System Block Diagram
GUITAR
INPUT
OVERDRIVE
GAIN
REVERB
LEVEL
REVERB
IN
8 OHM
INTERNAL
SPEAKER
LINE
OUT
REVERB
OUT
OVERDRIVE
LEVEL
12AX7A
V1A
12AX7A
V1B
12AX7A
V2A
12AX7A
V2B
PHASE
SPLITTER
EL84
EL84
12AX7A
V3A
12AX7A
V3B
BASS TREBLE MID
