9. SPECIFICATIONS
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
• Optional Components
HY-TB1 (Tile Bar Bridge): Place this bridge on the ceiling frame when mounting the speaker unit to
a weak suspended ceiling.
HY-TR1 (Trim Ring): Use this ring when mounting the speaker in pre-existing holes that are
larger than the designated 200 mm (7
7 /
8
") in diameter.
HY-AH1 (Anchor Hanging Bracket): Attach this bracket to an anchor bolt when mounting the speaker unit to a
weak ceiling.
HY-BC1 (Back Can): Use this Back Can when mounting the speaker unit in exposed hanging
applications.
F-2322C F-2352C
Bass reflex type
30 W (High Impedance)
Continuous pink noise: 60 W (8 Ω), 30 W (16 Ω)
Continuous program:
120 W (8 Ω), 60 W (16 Ω)
100 V line: 330 Ω (30 W), 1 kΩ (10 W), 3.3 kΩ (3 W), 10 kΩ (1 W)
70 V line: 170 Ω (30 W), 330 Ω (15 W), 1 kΩ (5 W), 3.3 kΩ (1.5 W), 10 kΩ (0.5 W)
25 V line: 170 Ω (3.7 W), 330 Ω (1.9 W), 1 kΩ (0.6 W), 3.3 kΩ (0.2 W),
10 kΩ (0.06 W)
16 Ω, 8 Ω
90 dB (1 W, 1 m)
70 – 20,000 Hz (–10 dB), 50 – 20,000 Hz (–20 dB)
at installation in 1/2 free sound field
(Measured by installing the unit in the center of a ceiling.)
12 cm (5") cone-type High frequency: Balanced dome-type
Low frequency: 12 cm (5") cone-type
ø200 mm (7 7 /
8
")
Maximum ceiling thickness: 37 mm (1 29 /
64
")
Removable locking connector with screw-down terminals
(2 input terminals and 2 bridge terminals)
Solid copper wire: ш0.5 – ш1.6 mm (equivalent to AWG 24 – 14)
Stranded copper wire: 0.2 – 2.5 mm 2 (equivalent to AWG 24 – 14)
Enclosure: Steel plate, plating
Baffle: Fire-resistant ABS resin (resin material grade: UL-94 V-0 or
its equivalent), black
Rim: Fire-resistant ABS resin (resin material grade: UL-94 V-0 or
its equivalent), white, paint
Punched net: Steel plate, white, paint
ø230 mm (9
1 /
16
") x Depth 200 mm (7 7 /
8
") ø230 mm (9 1 /
16
") x Depth 229 mm (9 1 /
64
")
3.7 kg (including mounting accessories)
Model No.
Enclosure
Rated Input
Power Handling Capacity
Impedance
Sound Pressure Level
Frequency Response
Speaker Component
Mounting Hole
Input Terminal
Usable Cable
Finish
Dimensions
Weight
Front grille ............................................................ 1
Ceiling reinforcement ring .................................... 1 Safety wire (approx. 60 cm or 23 5 /
8
") .................. 1
Paper pattern ....................................................... 1
533-06-093-1C
