.38.
Parts# Description
Parts# Description
Parts List-
Standard Parts
TTD210016 DIFF HOUSING SET
TD210017 DIFF GEAR & SHAFT SET
TD210018 DIFF OUTDRIVE SET (FRONT & REAR)
TD210020 FRONT DRIVESHAFT SET (1 PAIR)
TD210021 REAR DRIVESHAFT SET (1 PAIR)
TD210023 COMPLETE DIFF SET (FRONT OR REAR)
TD210026 DIFF SEAL SET
TD210027 DRIVESHAFT COUPLING SET (FRONT OR REAR)
TD210028 WHEEL HEX SET (1 PAIR)
TD210030 DRIVESHAFT COUPLING SET (MID DRIVESHAFT)
TD220004 REAR STIFFENER MOUNTING SET
TD230015 FRONT SHOCK SET (1 PAIR)
TD230016 REAR SHOCK SET (1 PAIR)
TD230018 SHOCK O-RING SET (4 SHOCKS)
TD240002 SERVO HORN & STEERING PARTS SET
TD260003 HUB BEARING SET
TD270004 STEERING PLATE FITTINGS SET
TD310043 WHEEL NUT (4pcs)
TD310046 GEAR BEARING TUBE
TD310057 SHOCK BOOT FRONT (2pcs)
TD310058 SHOCK BOOT REAR (2pcs)
TD310059 CVD BOOT (4pcs)
TD310064 REAR DRIVESHAFT (1pc)
TD310065 WHEEL AXLE (1pc)
TD310066 FRONT DRIVESHAFT (1pc)
TD310074 DIFF RING GEAR 43T (1pc)
TD310084 INPUT GEAR (1pc)
TD310087 WHEEL HEX PIN (10pcs)
TD310092 MID SHAFT SNAP RING (10pcs)
TD310093 GEARBOX SET
TD310204 MID DRIVESHAFT FRONT (1pc)
TD310205 MID DRIVESHAFT REAR (1pc)
TD310206 DIFF OUTDRIVE (CENTRE DIFF)(2pcs)
TD310207 SPUR GEAR 60T (1M)
TD310267 CENTRE DIFF HEX BUSH (2pcs)
TD320011 FRONT BULKHEAD (RIGHT)
TD320012 REAR BULKHEAD (LEFT)
TD320014 REAR BULKHEAD (RIGHT)
TD320022 FRONT BULKHEAD (LEFT)
TD320028 BUMPER, BODY MOUNT & WING MOUNT SET
TD320083 MOTOR PLATE
TD320085 MAIN CHASSIS PLATE
TD320086 MID GEAR PLATE
TD320087 REAR STIFFENER BUSHING (2pcs)
TD320088 FRONT & REAR STIFFENER SET
TD320089 CHASSIS SIDE RAIL SET
TD320090 MID GEAR TOP PLATE, RADIO PLATE & SERVO MOUNT
TD320092 FRONT DISTANCE PLATE
TD320093 REAR DISTANCE PLATE
TD320135 BATTERY STAP SET
TD320140 MID GEAR PLATE
TD330070 SUSPENSION MOUNT ALUMINIUM FR
TD330071 SUSPENSION MOUNT REAR LEFT
TD330072 SUSPENSION MOUNT RF
TD330073 PIVOT BALL A-TYPE
TD330074 ANTI-ROLL BAR BALL (4pcs)
TD330075 ANTI-ROLL BAR PIVOT BALL
TD330076 SUSPENSION ARM BUSHING (4pcs)
TD330078 SUSPENSION MOUNT REAR RIGHT
TD330079 REAR SUSPENSION PLATE
TD330080 SHOCK BODY ALUMINIUM FRONT
TD330081 SHOCK CAP ALUMINIUM
TD330082 SHOCK PRELOAD NUT & O-RING (PAIR)
TD330083 SHOCK SEAL CAP (1pc)
TD330084 SHOCK BODY ALUMINIUM REAR
TD330086 REAR SHOCK TOWER
TD330087 FRONT SHOCK TOWER
TD330088 SHOCK SPRINGS: REAR BLUE (2pcs)
TD330089 SHOCK SPRINGS: FRONT BLUE (2pcs)
TD330097 SHOCK DIAPHRAGM (4pcs)
TD330099 SHOCK SEAL O-RING (8pcs)
TD330100 PIVOT BALL G-TYPE (4pcs)
TD330101 SHOCK MOUNT (2pcs)
TD330102 TURNBUCKLE M5x64mm (2pcs)
TD330103 TURNBUCKLE M5x48mm (2pcs)
TD330104 HINGE PIN INNER 59mm (2pcs)
TD330105 HINGE PIN REAR OUTER (2pcs)
TD330106 KINGPIN (2pcs)
TD330107 TURNBUCKLE M4x60mm (2pcs)
TD330110 FRONT SHOCK SHAFT (2pcs)
TD330111 SHOCK PISTON WASHER (10pcs)
TD330112 REAR SHOCK SHAFT (2pcs)
TD330117 FRONT SUSPENSION ARMS
TD330118 REAR SUSPENSION ARMS
TD330119 STEERING KNUCKLES (LEFT & RIGHT)
TD330120 REAR HUB CARRIER SET (0 & 1 DEGREE)
TD330121 PLASTIC BALL ENDS
TD330122 PLASTIC SHOCK PARTS & SHIMS
TD330131 C-HUBS 10 DEGREES (LEFT & RIGHT)
TD330132 C-HUBS 14 DEGREES (LEFT & RIGHT)
TD330133 SUSPENSION MOUNT INSERT SET
TD330204 ANTI-ROLL BAR FRONT 2.6mm
TD330209 ANTI-ROLL BAR REAR 2.6mm
TD330404 SUSPENSION MOUNT ALUMINIUM FF
TD340010 SERVO SAVER NUT (1pc)
TD340011 STEERING PLATE
TD340012 STEERING ARM SPACER (2pcs)
TD340013 SERVO SAVER SHAFT
TD340015 SERVO SAVER SPRING
TD340061 TURNBUCKLE M3x30mm (1pc)
TD340062 STEERING POST (2pcs)
TD340063 STEERING TRAY
TD390001 ANTENNA TUBE & CAP (1pc)
TD390004 DIFF OIL 2000cst
TD390006 THREAD LOCK
TD390007 BODY CLIP (10pcs)
TD390017 GEAR GREASE
TD390021 HEX-WRENCH SET (4pcs)
TD390032 DIFF OIL 7000cst
TD390045 SHOCK OIL 600cst
TD406001 DEX408 CLEAR BODY SET (Included DECALS & MASKS)
TD480009 REAR WING
TD490014 DEX408 DECAL SHEET
TD510006 WHEEL RIM WHITE (2pcs)
TD601003 BALL BEARING : 4PCS (10x15x4mm)
TD601004 BALL BEARING 6x10x3mm (4pcs)
TD601005 BALL BEARING 8x16x5mm (4pcs)
TD601007 BALL BEARING 12x18x4mm (4pcs)
TD701002 SETSCREW M3x4mm (10pcs)
TD701003 SETSCREW M3x5mm (10pcs)
TD701004 SETSCREW M3x3mm (10pcs)
TD701005 SETSCREW M3x10mm (10pcs)
TD701009 SET SCREW M4x5mm (10pcs)
TD701012 SET SCREW M4x12mm (10pcs)
TD704003 FLAT HEAD HEX CS SCREW M3x12mm (10pcs)
TD704004 FLAT HEAD HEX CS SCREW M3x6mm (10pcs)
TD704006 FLAT HEAD HEX CS SCREW M3x8mm (10pcs)
TD704007 FLAT HEAD HEX CS SCREW M3x10mm (10pcs)
TD704009 CAP HEAD HEX SCREW M3x10mm (10pcs)
TD704014 FLAT HEAD HEX CS SCREW M3x20mm (10pcs)
TD704022 CAP HEAD HEX SCREW M3x12mm (10pcs)
TD704024 CAP HEAD HEX SCREW M3x16mm (10pcs)
TD704048 CAP HEAD HEX SCREW M3x36mm (10pcs)
TD705001 BUTTON HEAD HEX SCREW M3x6mm (10pcs)
TD705002 BUTTON HEAD HEX SCREW M3x8mm (10pcs)
TD705011 BUTTON HEAD HEX SCREW M3x14mm (10pcs)
TD705012 BUTTON HEAD HEX SCREW M3x18mm (10pcs)
TD705013 BUTTON HEAD HEX SCREW M3x22mm (10pcs)
TD705014 BUTTON HEAD HEX SCREW M3x20mm (10pcs)
TD705015 BUTTON HEAD HEX SCREW M3x16mm (10pcs)
TD705016 BUTTON HEAD HEX SCREW M2.5x8mm (10pcs)
TD705022 BUTTON HEAD HEX SCREW M4x18mm (10pcs)
TD705031 BUTTON HEAD HEX SCREW M4x8mm (10pcs)
TD709007 SERVO WASHER ALUMINIUM 6x3x0.5mm
TD709011 PIVOT BALL BUSHING (10pcs)
TD709022 SHIM 8.0x10.0x0.1mm (10pcs)
TD709023 SHIM 13.0x16.0x0.1mm (10pcs)
TD709030 SHIM 4.0x8.0x1.2mm (10pcs)
TD712002 PIVOT BALL BUSHING : CONICAL 7x3x2mm (10pcs)
TD715001 LOCK NUT M3: LOW PROFILE (10pcs)
TD715002 LOCKNUT M3: STANDARD (10PCS)
