TRANSMITTER
The transmitter (Tx) requires 4 “AA”
batteries. Non-rechargeable alkaline or
rechargeable nickel-cadmium (NiCd)
or nickel-metal hydride (NiMH) cells
can be used. Do not mix old and new
cells, or mix non-rechargeable alkaline
cells with rechargeable NiCd or NiMH
cells, etc. See the SERVOS AND
ACCESSORIES section at the end of
this manual for optional rechargeable
NiCd and NiMH batteries and chargers.
Note the TTX240 transmitter does not
include a charge jack for rechargeable
cells. A separate “AA” cell charger will
be necessary.
To install the batteries, slide open the battery door on the bottom of the Tx
(see fi gure 1). Install the batteries in the holder as shown in the diagram (see
marks molded inside the case). Make sure to note the proper polarities on
each cell. Close the battery door.
IMPORTANT: Do not operate an R/C model with weak
batteries as it could result in reduced range and/or
possible loss of control!
Press the power switch to turn the Tx
on (see fi gure 2). The “POWER” LED
should illuminate. If not, turn off the Tx
and check the batteries to make sure
each cell is fi rmly in place and in the
proper direction. If the Tx LED blinks,
the batteries are low on power and
should be replaced.
When operating the model, carefully
rotate the Tx antenna so that it’s always
locked in the full upright position.
+
-
+
-
+
-
+
-
4 “AA”
Cells
Figure 1
Antenna
Power
LED
On/Off
Power
Switch
Battery
Cover
Steering
Rate
Throttle
Reversing
Steering
Trim
Steering
Reversing
Throttle
Trim
Figure 2
