Sure Heat 2008 Surefire SF278LP - Manual (Page 11)

Grill Assembly
a. Lay the Side Shelf Left Assembly (6A) on its side. Use
one (1) M6 x 10 phillips pan head screw to attach one
of the Handle Ends (6B) to the front of the shelf.
Note: Be careful not to scratch the side of the shelf.
b. Slide one end of the Handle Bar (6C) into the installed
handle end. Attach the second handle end using
the M6 x 10 phillips head screw while holding the
assembly in place.
c. Loosen the four (4) 5/16-24 Hex Head screws (6D) on
the left side of the grill as shown.
d. Attach the left side shelf (6E) by inserting the four
screws on the side of the grill head into the holes on
the left shelf.
e. Tighten the screws with a wrench.
f. Install one self-tapping screw (6F) into the bottom front
slotted hole of the shelf. This will permanently lock the
shelf in place.
STEP SIX
6A
6B
6C
Close view for Step 6f
11
6F
6E
6D
