7
Assemble hood and door to masonry base
Place the grill hood in the masonry base. 1.
A. Electrical outlet for rotisserie (optional)
B. Required gas cutout
Assemble igniter assembly
Install “AA” battery, negative end (-) first. 1.
Install spring and cap assembly and tighten securely. 2.
A. Igniter
A
Complete grill assembly
Insert the flavor grids into the cutouts with triangle ridges 3.
facing up.
Install main cooking grates on the ledges provided on the 4.
grill to create your cooking surface.
Rest bread warming grate on 4 slots above cooking grid 5.
A. Flavor grids
B. Main cooking grates
C. Bread warming rack
A
B
C
A
B
Built-in dimesions
a 30 1/2” f 2”
b 16 1/8” g 1 1/8”
c 11 h 18 3/4”
d 8” i 18 1/2”
e 8” j 1 1/2”
A
