Fig. 46
CONNECTING IGNITER WIRES
1. Attach the large connector of the loose packaged
side burner wire to the terminal under the side
burner head. (See Fig. 45)
2. Connect the other end of the side burner wire to
one of the outlets on the electronic igniter. NOTE: It
does not matter which wire goes where on the elec-
tronic igniter. (See Fig. 46)
3. Plug the remaining wires coming out of the side of
the grill into the terminals of the electronic igniter.
(See Fig. 46)
Fig. 45
Assembly
13
