Specifications
*Temperature range is for operation in shaded location.
Specifications are subject to change.
Specifications for SunBriteTV Model 5515HD
Front View
Side View
Dimensions with detachable speaker module.
All measurements are in inches
Screen
55-inch diagonal TFT Active Matrix LCD with LED Backlight
Resolution
1920 x 1080 full-HD 1080p, 120 Hz Frame Rate
Aspect Ratio
16:9
Contrast Ratio
1300:1
Viewing Angle
176
o
Response Time
12 milliseconds
TV formats
1080p, 1080i, 720p, 480p, 480i
Input Connectors:
RF
HDMI
Composite
Video Component
PC
Antenna/CATV (ATSC/QAM/NTSC) x1
HDMI™ Input x2
S-Video x1 and Composite Viceox1, L/R Audio Inputs x1
YPbPr plus Stereo Audio x2
15-pin D-sub VGA plus Stereo Audio
Control Set
RS232 Serial, Discrete IR Control, Concealed IR Window
Audio Out
SPDIF, Digital (fixed output)
1/8” Stereo mini jack, Analog (variable output)
Speakers
10-watt x 2 channels, water-resistant detachable speaker
module
Exterior
Powder-coated aluminum
Input Power
100-240 VAC, 50-60 Hz 2.0 A Max
Operating Temp.
-24
o
to 122
o
F. (-31
o
to 50
o
C.) *
Non-op. Temp.
(Off-mode with
power applied)
-24
o
to 140
o
F. (-31
o
to 60
o
C.)
The non-operating temperature feature requires power to
be applied
Accessories Included
Water-resistant remote control
TV Dimensions
52.46” W x 31.44 ” H (33.50” H with speakers) x 7.80” D
Weight
104.0 lbs; 109.0 lbs with speakers
Residential Warranty
Two-years, in-factory, parts and labor
Commercial Warranty
One-year parts and labor
Mount Pattern
600mm x 200mm
VESA MOUNTINg PATTERN
600mm x 200mm
