LED Indicators
VGA LED Indicator
Type of Monitor Connected
Video Source
Device Active
Emit Green and Flash Blue (3 Times)
HDMI
No
Emit Green and Flash Blue (2 Times)
DVI w/ adapter (not included)
No
Emit Blue and Flash Green (3 Times)
HDMI
Yes
Emit Blue and Flash Green (2 Times)
DVI w/ adapter (not included)
Yes
Emit Green and Flash Red (1 time)
No monitor attached
No
Emit Blue and Flash Red (1 time)
No monitor attached
Yes
HDMI LED Indicator
Type of Monitor Connected
Video Source
Device Active
HDCP
signal
Detected
Emit Green and Flash Blue (3 Times)
HDMI
No
N/A
Emit Green and Flash Blue (2 Times)
DVI w/ adapter (not included)
No
N/A
Emits Blue and goes off (3 times)
HDMI
Yes
N/A
Emits Blue and goes off (2 Times)
DVI w/ adapter (not included)
Yes
N/A
Emits Purple and goes off (3 times)
HDMI
Yes
Yes
Emits Purple and goes off (2 times)
DVI w/ adapter (not included)
Yes
Yes
Emit Green and Flash Red (1 time)
No monitor detected
No
N/A
Emit Blue and Flash Red (1 time)
No monitor detected
Yes
N/A
