Oil Mist Exhaust Filters • Rev. MA4031103
Page 10
SOLBERG
*Note: Spare parts are for standard products. See page 4 for replacement element.
3. Always check inlets/outlets, element base and its components when replacing
element to insure cleanliness. Wipe clean if necessary.
4. Operate only when a proper seal exists.
5. Never operate without absolute assurance that V-clamp is secured correctly along
entire diameter of canisters (where used). Check along V-clamp for wear. Replace if
any distortion occurs due to handling and usage.
SPARE PARTS LIST:
EF, EE/SV, HDL, SDL and VPST
Housing Element
Top Wingnut(s)/ O-Ring/ Vband/ Element Wingnuts/ O-Ring/
Parent Model Top O-Ring Hexnut(s) Washer(s) Bolts Seal Bolt Washer(s)
Model-Element-Connection Model No. Model No. Model No. Model No. Model No. Model No. Model No. Model No.
HDL-PSG848-xxx T848 OR675 WN38X16 WR38BE BS38162 BG281 N/A N/A
HDL-PSG850/1-xxx TDV850 OR750 N/A N/A VB700 BG412 ST38200 OR056
HDL-PSG860/1-xxx TV860 OR750 N/A N/A VB700 BG412 ST38200 OR056
HDL-PSG244/2-xxx TDV238 OR1250 N/A N/A VB1525 OR600 BH50X13 WRCP50
HDL-PSG344/2-xxx TP1400 OR1200 HN38X16 WL38X16 BT38163 OR600 BH50X13 WRCP50
HDL-PSG374/2-xxx TP1850 OR1600 HN38X16 WL38X16 BT38163 OR800 BH50X13 WRCP50
HDL-PSG474/2-xxx TP1850 OR1600 HN38X16 WL38X16 BT38163 OR800 BH50X13 WRCP50
HDL-PSG476/2-xxx TP2100 OR1900 HN38X16 WL38X16 BT38163 OR900 BH50X13 WRCP50
EE-GL915-xxx N/A OR300 N/A N/A N/A N/A ST25075 OR038
EE-GL925-xxx N/A OR247 N/A N/A VB115 N/A
EFDB-FG9-xxx TF500375 N/A N/A OR056 ST38125 N/A N/A N/A
EFDB-FG11-xxx N/A N/A N/A N/A N/A N/A
EF-FG3-xxx TF25025 N/A N/A OR038 ST25075 N/A N/A N/A
EF-FG5-xxx TF25025 N/A N/A OR038 ST25150 N/A N/A N/A
EF-FG7-xxx TF25025 N/A N/A OR038 ST25250 N/A N/A N/A
EF-FG9-xxx TF500375 N/A N/A OR056 ST38125 N/A N/A N/A
EF-FG10-xxx TF500375 N/A N/A OR056 ST38125 N/A N/A N/A
EF-FG20-xxx TF10250375 N/A N/A OR056 ST38125 N/A N/A N/A
EF-FG24-xxx TF10250375 N/A N/A OR056 ST38200 N/A N/A N/A
VPST-PSG850/1-xxx TDV850 OR750 N/A N/A VB700 BG412 ST38200 OR056
VPST-PSG860/1-xxx TV860 OR750 N/A N/A VB700 BG412 ST38200 OR056
VPST-PSG244/2-xxx TDV238 OR1250 N/A N/A VB1525 OR600 BH50X13 WRCP50
VPST-PSG474/2-xxx TP1850 OV1600 HN38X16 WL38X16 BT38163 OR800 BH50X13 WRCP50
