Page 11
3. Securing SpinMeister ™ to housing.
A. Gently push the SpinMeister
™ and clamp down on the housing inlet
tube. Note: DO NOT push the SpinMeister ™ down as far as it will go,
doing so will damage the SpinMeister
™! The inlet tube should not
exceed top of the SpinMeister ™ internal tube.
B. Tighten hose clamp by using a flat head screwdriver or ratchet and
rotating the screw clockwise.
4. Disconnecting canister top from canister base.
A. Push down and twist the housing top to release. Use care to support the
bottom housing while removing housing top. Fitting damage can occur if
fitting it torqued in the wrong direction.
Figure C.3.1: Inlet tube and SpinMeister ™ limit.
Do not exceed
this point!
Figure C.4.1: Housing top removal directions.
1.) Push Down 2.) Twist
