33
Encore 1450 Non-Catalytic Woodburning Stove
30002425
1. Not interchangeable, due to a heat-reflective coating on the room
side of the panels.
2. Included in #0004345 ceramic handle assembly.
Encore Woodburning Stove
Model 1450 (continued)
Item Description Part Number Item Description Part Number
1. Flue Collar (8”) See Chart Pg. 33
2. Inner Back 30002385
3. Left Heat Deflector 30002442
4. Right Heat Deflector 30002441
5. Left Griddle Quad 30002399
6. Right Griddle Quad 30002401
7. Griddle 30002386
8. Griddle Handle Assy 30002775
9. Top See Chart Pg. 33
10. Damper Housing 30002413
11. Damper 30002389
12. Damper Tabs (3) 1601488
13. Damper Rod 1600851
14. Damper Handle Screw 1/4-20 x 3³⁄₈” NT 1201310
15. Damper Handle,Wood 1600664
16. Steel Handle Stub 30002720
17. Left Side See Chart Pg. 33
18. Left Air Manifold (Inner side) 30002408
19. Right Air Manifold (Inner side) 30002409
20. Right Side See Chart Pg. 33
21. Thermostat Handle Shaft w/set screw 30002716
21a. Thermostat Handle Wood 1600660
21b. Round Hd, Sl 8-32 x 2 Screw 1201243
22. Grate 30002390
23. Bottom Outer 30002391
24. Ashlip See Chart Pg. 33
25. Andiron (2) 30002397
26. Leg See Chart Pg. 33
27. Leg Leveler 1201745
28. Pawl Assembly Short Adjustment 30002362
29. Ashdoor 30002392
30. Ashdoor Handle (Wood) 1600663
31. Ashdoor Hinge Pin 30002473
32. Cotter Pin, Ashdoor 30001749
33. Ashdoor Hinge Lower 30002404
34. Ashpan 1601025
35. Ashpan Bracket 1601039
36. Ashpan Cover 1601027
37. Airwash Manifold 30002407
38. Front See Chart Pg. 33
39. Left Door See Chart Pg. 33
40. Door Hinge Strip (2) 1308634
41. Right Door See Chart Pg. 33
42. Door Gasket 5/16 Med. Density 6ND 1203588
43. Glass Gasket 1203556
44. Left Door Glass 1 30002476
45. Right Door Glass 1 1408629
46. Spacer 3/8 x 1-Z 1201779
47. Damper Ramp 1301811
Socket Set Screw Adjuster 1200436
PH Flat Hd Screw 1200809
Hex Nuts 1203210
48. Handle Base Stub 2 30002714
49. Ceramic Handle 2.78 Lg 2 20006381
50. Handle Bolt 2 1201294
51. Friction Spring 1201846
52. Washer 1202471
53. Pin, Long, Door 30002727
54. Inner Bottom 30002406
55. Primary Air Plate 30002415
56. Lower Brick Retainer 30002416
57. Hinge, Upper Ashdoor 30002403
58. Fountain Assembly CDW 30002100
59. Insul Gasket Shoe 30002418
60. Refractory Shoe 30002419
61. Refractory Lower 30002414
62. End Insulation 30002420
64. Right End Refractory 30002421
65. Left End Refractory 30002475
66. Primary Air Flap 30002443
67. Primary Air Shaft 30002841
68. Primary Air Linkage 30002445
69. Outer Back Assembly 30002450
70. Bottom Heat Shield 30002446
71. Griddle Gasket 1203668
72. Rear Side Bracket 30002457
73. Brick Support Bracket 30002480
74. Holder, Door Handle 30002909
75. Front Steel Handle w/Shaft 30002717
76. Ashdoor Handle Shaft 1600622
77. Hex Jam Nut 1203290
78. Bracket, Upper Side 30002667
79. Rheostat Bracket 30002863
