SIGTRONICS SEP-40 HEARING PROTECTOR PARTS IDENTIFICATION BREAKDOWN
ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION
1 800048 HEADBAND , WITH CUSHION, SE-40 7 100367 YOKE, EAR CUP MOUNT, METAL 13 100258 CLIP, HEADBAND GUIDE, PLASTIC
2 100251 E-RING, EAR CUP TO YOKE RETAINER 8 100369 EAR SEAL, FOAM FILLED 14 100393 CLIP, ANTI-ROTATION, YOKE, PLASTIC
3 100252 NUT, HEX, 8-32, LOCKING 9 100373 SLIDE, YOKE BRACKET, LONG, NYLON 15 100383 HEADBAND, METAL, STANDARD
4 100361 EAR CUP, PRINTED AND DRILLED 10 100374 FOAM, SOUND ATTENUATING. NOTCHED, 1/2 INCH 16 100384 BRACKET, YOKE SUPPORT WITH TANG
5 100363 SCREW, 8-32 X 1/2, PHILLIPS HEAD 11 100376 FOAM, SOUND ATTENUATING. RECEIVER HOLE, 1/2 INCH 17 100257 OPTIONAL – HEADBAND, METAL, LARGE
6 100364 SCREW, 8-32 X 3/8, PHILLIPS HEAD 12 100379 FOAM, SOUND ATTENUATING, RECEIVER COVER, 1/4 INCH 18 100402 OPTIONAL – EAR SEAL, GEL FILLED
3-20-2009
