Model SE-41RPTT
Headset Instructions
The SE-41RPTT series headset is adjusted at the factory for immediate use. The
headset is equipped with a single plug and a coiled cord.
The headband is adjustable through a full range of motion, and the locking nuts
may be tightened to allow you to custom fit the headphone. Place the head-
phone over your head and adjust the slides up until minimum pressure is felt on
the top of your head. For maximum noise attenuation, the clamping pressure of
the headband has been set at the factory. Releasing the clamping pressure by
bending the headband is not advised, because loss of attenuation will result.
The microphone boom is fully adjustable and will rotate 180 degrees for use on
the left or right side of the head. The locking screw that secures the boom to the
ear cup is factory set to insure the correct tension. Turning it will not change the
tension, because the nut on the inside of the cup will turn as well.
Microphone placement should be at the corner of the mouth, approximately
¼” from the lips. The exclusive thumb screw on the mic boom may be used to
assure proper placement.
Your SE-41RPTT headset has a push to transmit switch located on the mic side ear
cup. When the headset is connected to a radio, depressing this switch will cause
the radio to transmit. The switch is not used for intercom function.
When you first connect the headset, turn the volume control on the headset up
to the full clockwise position, then adjust the listening volume with the audio
control of either your radio or intercom as appropriate. If applicable, crew mem-
bers should also turn their individual headset volumes up fully. Doing this allows
for a full range of adjustment for each passenger, since those with the most acute
hearing can turn their headset volume down, if necessary.
continued on back…
The headset parts may be cleaned with mild soap and water using a soft cloth.
Then dry immediately. Caution: Do Not immerse any part of the headset in
water or any other liquid. Be especially careful not to allow the microphone to
become wet! Exposure to moisture may cause internal corrosion and failure and
will void your manufacturers warranty.
Cleaning will help the headset maintain its “like new” condition for many years.
WINDSCREEN
The microphone windscreen will reduce annoying wind noise and breath pops
picked up by headset microphones. It also protects the microphone element
from dirt and moisture. The windscreen should be washed regularly to maintain
hygiene and avoid clogging. Wash in warm water and mild soap. Rinse thor-
oughly and make sure it is completely dry before putting it back on.
To remove the windscreen, take out the screw that holds the microphone on the
boom and grasp the windscreen lightly along its entire length and slip it off.
Put the windscreen on the microphone by gently pulling from the open end. Do
not pull it so tightly that it stretches against the end of the microphone.
WARRANTY
Your headset is covered by a limited one-year parts and labor warranty. Please
see the enclosed warranty card for details.
You may refer to the parts list on the reverse side, if you choose to replace parts
yourself. The parts list describes parts for this particular headset only. Parts lists
for other models are available on our Web Site or can be obtained by contacting
Sigtronics Corporation.
Sigtronics Corporation
178 East Arrow Highway
San Dimas, CA 91773
Phone: 909 305-9399
E-mail: [email protected]
Web Site: www.sigtronics.com
