S I G T R O N I C S ’ D V M - 2 0 0
Add a Diagnostic Tool to your panel!
The DVM-200 helps you
diagnose low cranking voltage,
inoperative alternator or
generator, loose drive belts,
malfunctioning voltage
regulator, system short circuit
problems and other low voltage
or high voltage conditions.
Try a little preventative medicine by using a
Sigtronics’ Digital Voltmeter. Early detection of
potentially hazardous electrical problems may
save costly equipment.
The digital voltmeter provides precise voltage
readings and therefore can allow the pilot to
detect a malfunction. This enables you to make
‘‘power down’’ decisions to conserve electrical
energy for critical operations, such as flap and
gear extension, and communications. The
DVM-200 is a definite
must
for the conscien-
tious pilot!
•
PRECISION INSTRUMENT- The Sigtronics
DVM-200 Digital Voltmeter is a precision
electronic instrument which employs the latest
in digital technology. It provides the pilot with a
means of detecting minute changes in electrical
system performance which could be a sign of
trouble and impending system failure.
•
ACCURACY - Precise monitoring of the
electrical system voltage is possible with an
accuracy of +1% of full scale. The resolution is
0.1 volts.
SPECIFICATIONS:
•
Dimensions: 2.5” x 2.5” x 3.5” deep
•
Voltage Requirement: 8-35 VDC
•
Operates on 1 2V or 24V systems
•
Current Drain: 0.01 amps, exclusive
of lighting system.
•
LARGE LCD DISPLAY is easy to view in
sunlight. Back lighting is provided for night
flying. The lighting circuit can be connected to
the aircraft panel light dimmer circuit to be
dimmed with the other panel lights.
•
DESIGNED TO FIT the standard 2-1/4”
instrument hole, the DVM-200 is easy to
install. The unit comes with the connection
cable and a back lighting kit.
•
Accuracy: ±1% of full scale
•
Resolution: 0.1V
•
Weight: 3.5 ounces
•
Warranty: One year parts and labor
