12
at -2 to match the process value to the independent thermometer. To
navigate the control to the Offset Calibration mode, push the PGM button
once and then push the up arrow once and the bottom display
should read CONF. Then push the PGM button again and the display
should say INP. Push the PGM button again and the display should
read INP1. Push the PGM button again and the display should read
SENS. This enters you in the Input/Configuration Menu. To navigate
through the menu, press the up and down arrows.
Press the up or
down arrow repeatedly until you reach OFFS in the bottom display.
Then, push the PGM button once, and the display will start flashing.
While flashing, use the up or down arrow to set the desired Offset.
After the display stops flashing, push the Exit Button repeatedly until
the NORMAL Display is reached.
6.7 Setting High Limit: Prior to setting the High Limit Control be certain the
Main temperature Control has reached the input set point and has
remained stable for several hours. This will insure that the High Limit is
set at the proper temperature. As stated in 4.3, the High Limit control
should be at maximum position, clockwise. Now turn the thermostat
counter-clockwise using a flat-head screwdriver until the High Limit
Activated indicator light comes on. Next turn the thermostat clockwise
just until the indicator light turns off. Then turn the thermostat clockwise
two (2) minor increments on its scale past the point where the indicator
light went out. This will set the High Limit at approximately 10

C above
the Main Temperature set point.
