5
STEP 4
Run the power cord through the guide on the bottom of the BASE-back by tucking the
cord under the tabs. Set fan upright on the base and it is ready for use.
STEP 3
Pass the Power Cord through the center hole of the BASE.
Align the BASE front with the FAN front and insert the four posts on the FAN body into
the four holes on the top of the BASE. It will only go one way. Place the 4 Fan-Body
SCREWS into the holes through the bottom of the base and securely tighten.
6
ON/OFF: Turns power ON & OFF
(10 second air blow after shut down)
Fan Speed Selection: Allows four different speed settings
Setting the Timer: There are 48 total settings. The time can be set in 1/2 hour
increments with each push of the button. 1/2 hour, 1 hour, 1-1/2 hour, 2 hours,
up to 24 hours. To set the timer, hold down the button for 2 seconds, then
add or reduce time on the clock.
High Low Medium
D
See further instructions on use, care and safety.
Heater&Fan Assembly Control Panel
- +
Fan Speed
LCD Display
Power
Oscillating
Timer
ECO
Fan Mode Heater Mode
A Heater
Auto/Low/High
Control
Oscillating
Heater
Thermostat
Setting
Power
Timer
