Channel Vision ID652 User Manual
Dual voice coil in-ceiling speakers, Id652, Hannel

Features:
•
Mica-filled polypropylene woofer with true rubber
surround
•
Dual ½" fluid-cooled ultra-wide dispersion mylar
tweeters
•
Tweeters swivel independently up to 45 degrees
•
Tweeter protection using thermal sensing polymer
switches
•
Dual 2nd order Butterworth crossover networks
•
Recommended power: 5W to 100W
Channel Vision’s ID652 dual voice coil in-ceiling loudspeakers deliver stereo sound from a single speaker.
They are ideal for balanced coverage and for use in confined areas where only one speaker can fit such as
small rooms, bathrooms, and hallways.
Dual Voice Coil In-Ceiling Speakers
234 F
ISCHER
A
VENUE
• C
OSTA
M
ESA
, CA 92626
(714) 424-6500 • (800) 840-0288 • (714) 424-6510 fax
www.channelvision.com • email: [email protected]
A
RIA
BY
C
HANNEL
V
ISION
™
© 2003, C
HANNEL
V
ISION
™
spec sheet #
A-0502
rev. 7/03
Specifications:
Frequency Range 55Hz - 20kHz ± 3dB
Sensitivity 89dB (for 2.83V pink noise)
Power Handling 100 Watts
Drivers 2- ½” Mylar dome tweeter
1- 6 ½” polypropylene woofer
Impedance 8 ohms
Finish ABS plastic
Dimensions 9¼” OD. 3½” height
(from surface of wall board)
Weight 5 lbs as shipped
Hole Cutout Dimension 8" in diameter
ID652
