Appendix B - Hardware Specifications 49
Cyclades-PR2000
DB-25 - M.34 Adaptor
DB-25 Female
Signal
PGnd
RTS
CTS
DSR
Gnd
DCD
TxD/V.35 (B)
TxD/V.35 (A)
RxD/V.35 (B)
RxD/V.35 (A)
TxClk_DTE/V.35 (B)
TxClk_DTE/V.35 (A)
TxClk_DCE/V.35 (B)
DTR
TxClk_DCE/V.35 (A)
RxClk V.35 (A)
RxClk V.35 (B)
Male
Retention
Screw
Female
Retention
Screw
Female
Retention
Screw
M.34 Male
Signal
PGnd
RTS
CTS
DSR
Gnd
DCD
TxD (B)
TxD (A)
RxD (B)
RxD (A)
TxClk_DTE (B)
TxClk_DTE (A)
TxClk_DCE (B)
DTR
TxClk_DCE (A)
RxClk (A)
RxClk (B)
Pin
A
C
D
E
B
F
S
P
T
R
AA
Y
W
H
U
V
X
Pin
1
4
5
6
7
8
11
12
13
14
16
18
19
20
21
23
25
FIGURE B.7 DB-25 - M.34 ADAPTOR - DB-25 FEMALE TO M.34 MALE
