Santec TH-5534 User Manual
Installation instructions, Center mark, Cold hot

W
A
L
L
W
A
L
L
Center Mark
9
0
1
0
0
1
1
0
Shown from top view
9
0
1
0
0
1
1
0
Temperature Dial
Numerical Dial
Mounting Screw
COLD
HOT
PROJECTION ON
THE SLEEVE
Align the projection on the sleeve with projection
on the top lip of the body.
And then slide it on the valve body.
1
2
3
TH-5534 (DUAL THERMAX THERMOSTATIC VALVE AND TRIM)
INSTALLATION INSTRUCTIONS
Page 1
Put on the plate aligned to the wall and screw in the plate mounting screws.
Put on thermostatic dial on the valve stem.
Align 100 mark with the center mark on the sleeve to adjust the temperature at
lowest level.
Handle with flange and body goes on to the stem co-axially.
W
a
ll
W
a
ll
COLD
HOT
GROOVE ON THE
VALVE BODY
PROJECTION ON
THE SLEEVE
Temperature Dial
Numerical Dial
Mounting Screw
