Santec 708420 User Manual
Enzo collection, Enzo slide bar assembly with personal shower #7
ENZO COLLECTION
ENZO COLLECTION
ENZO SLIDE BAR ASSEMBLY WITH PERSONAL SHOWER #7
ENZO SLIDE BAR ASSEMBLY WITH PERSONAL SHOWER #7
KEEP THIS INSTRUCTION BOOKLET FOR FUTURE REFERENCE
PAGE 01
708420 __ - __
ITEM NUMBER
1
2
3
4
7
5
8
6
1
2
3
4
5
6
7
8
Base Body with Flange, Slide Bar *
Mounting Screw, Shower Slide Bar
Sliding Bar*
Sliding Bracket, Sub Assembly*
Base Cover-cap, Sliding Bar*
Drywall Screw, Mounting Pack
Mounting Post Sub Assembly*
Spray Assembly, Modena Personal Shower*
PA-2838
PM-928
SL-700-1
SL-700-2
SL-800-7
PM-016
PM-927
PS-700S
Part Description
#
Part #
* Please Specify the finish when you order this part
f
1 & 1/5”
Water Inlet
f
2.2”
27”
f
0.7”
WITH CAP ON
3
3/8
”
24.8”
Wider end
up
Narrower end
Down
Note. Illustration may not depict actual products
