Santec 7089SE User Manual
7089se, Supply elbow, Modena collection
PAGE 01
MODENA COLLECTION
SUPPLY ELBOW
##
PART DESCRIPTION
PART #
1
Supply Elbow*
SE00-1
* Please specify the finish when ordering the part.
KEEP THIS INSTRUCTION BOOKLET FOR FUTURE REFERENCE
7089SE _ _-_ _
ITEM NUMBER
1
INSTALLATION INSTRUCTIONS
Water inlet
pipe
1. Place SUPPLY ELBOW in the wall hole sized ½”.
2. Screw in the water inlet pipe.
FLUSH BOTH SUPPLY LINES BEFORE INSTALLATION
.
AFTER FLUSHING , SHUT OFF BOTH SUPPLY LINES.
SIZE FOR WATER INLET PIPE IS 1/2”
3. Connect a hose for water outlet.
Hose for Water
outlet
