Santec 708224 - Manual

PAGE 01
MODENA COLLECTION
ALL BRASS BODY DOUBLE BODY SPRAYS WITH PLATE
## PART DESCRIPTION PART #
1
2 All Brass Body Spray Assembly* 708204
* Please specify the finish when ordering the part.
KEEP THIS INSTRUCTION BOOKLET FOR FUTURE REFERENCE
708224 _ _-_ _
ITEM NUMBER
Rubber Washer Flange PM-400
1
2
INSTALLATION INSTRUCTIONS
1. Place rubber washer PM-400 in the groove of the body spray.
And Gasket in the plate groove.
FLUSH BOTH SUPPLY LINES BEFORE INSTALLATION
.
AFTER FLUSHING , SHUT OFF BOTH SUPPLY LINES.
SIZE FOR WATER INLET PIPE IS ½ INCH
”
3
Plate PO-2603 3
4 Plate Gasket PM-872
4
