E S T A T E S E R I E S A R K O C O L L E C T I O N
P R E S S U R E B A L A N C E D T U B / S H O W E R
T R I M W I T H “ A R ” H A N D L E S
M O D E L : 6 7 3 4 A R 1 0 - T M
6 7 3 4 A R 7 5 - T M
KEEP THIS INSTRUCTION BOOKLET FOR FUTURE REFERENCE
I m p o r t a n t : P l e a s e re g i s t e r y o u r p ro d u c t o n l i n e a t w w w. s a n t e c f a u c e t . c o m w i t h i n
3 0 d a y s o f p u rc h a s e . S a n t e c re s e r v e s t h e r i g h t t o re q u e s t a d d i t i o n a l d o c u m e n t s
b e f o re s e r v i c i n g w a r r a n t y re q u e s t s .
0 1 0 2
Specifications
Description
This product is precision engineered to provide satisfactory performance provided it is installed and
operated in accordance with our recommendations contained in this manual. In order to fully enjoy the
comfort, safety and the reliability of your pressure balancing valve, be certain to familiarize yourself with the
contents of this manual.
Trim
plate
Finished wall
Handle
Set screw
Allen
key
Foam
strip
Sleeve Plate
screws
Specification and Dimensions
Minimum operating pressure 20 psi
Maximum operating pressure 145 psi
Maximum test pressure 500 psi
Hot and cold water inlets ½" IPS
Shower outlet ½" IPS
Flow capacity 5 USGPM @ 50 psi
3 5
16 "
Ш7"
Ш2 1
2 "
11"
Ш2 1
4 "
6 1
4 "
WALL LINE
78"
(1981 mm)
FLOOR
LINE
½”
½”
33"
Min 36"
