Santec 6664BO - Manual

B R A V O / M A G G I O C O L L E C T I O N
E S T A T E S E R I E S
T O W E L R I N G
M O D E L : 6 6 6 4 B O 1 0
6 6 6 4 B O 7 5
KEEP THIS INSTRUCTION BOOKLET FOR FUTURE REFERENCE
I m p o r t a n t : P l e a s e re g i s t e r y o u r p ro d u c t o n l i n e a t w w w. s a n t e c f a u c e t . c o m w i t h i n
3 0 d a y s o f p u rc h a s e . S a n t e c re s e r v e s t h e r i g h t t o re q u e s t a d d i t i o n a l d o c u m e n t s
b e f o re s e r v i c i n g w a r r a n t y re q u e s t s .
0 1 0 2
Installation Instructions
Place the trim parts against the assigned wall location. Make sure that the ring is leveled. Mark the ring
post flange position and remove the trim. 1.
Using the Allen key provided, remove the mounting post from the ring post. Press the mounting post
against ring post position on the wall and mark the screw hole positions.
NOTE: MAKE SURE THE ALLEN SCREW HOLE ON THE MOUNTING POST IS FACING DOWN
WHEN SECURING TO WALL.
2.
WALL
INSTALLING ON WOODEN SURFACE
For wooden surface, the mounting post can be
secured by screwing the screws directly into the wall.
INSTALLING ONTO DRYWALL SURFACE
Using a drill, pre-drill holes for the anchors. Insert the
anchors into the wall. The mounting post can be
secured by screwing the screws into the anchors.
INSTALLING ONTO A SOLID SURFACE
Measure the dimensions carefully. Using a drill,
pre-drill the holes. Secure the mounting post by
screwing the screws into the wall.
ring post mark
mounting post
