Santec 4134BL User Manual
4134bl _ _ - tm, Inspected by, Pressure balanced tub and shower with “bl” handle
Ш2.500"
7.349"
Ш2.250"
2.515"
3.516"
PAGE 01
PRESSURE BALANCED TUB AND SHOWER WITH “BL” HANDLE
##
PART DESCRIPTION
PART #
1
2
3
4
5
6
7
Complete Shower head *
8” Shower Arm *
Complete BL Handle for Shower *
Complete Wall Mount Tub Spout *
P0-285
P0-286
P0-2E81
* Please specify the finish when ordering the part.
KEEP THIS INSTRUCTION BOOKLET FOR FUTURE REFERENCE
Shower Flange *
P0-2520
00YY-BL
Ph29999
6
6
7
7
Tub/shower Trim Plate *
8
Plate Screws (2) *
9
Valve Sleeve *
P0-2101
P0617
1
1
2
2
3
3
INSPECTED BY
9
9
10
10
10
Diverter Body *
P0-2102
11
Diverter Knob *
P0-2103
4134BL _ _ - TM
MODEL NUMBER
11
11
12
P0-022
Shower Plate Sealing Foam Strip
ESTATE SERIES BRITANI COLLECTION
4
4
12
12
Allen Key
4134GL10 - TM 4134GL75 - TM
4134GL23 - TM 4134GL41 - TM
8
8
Pm034
PM-031
5.569"
2.315"
1.246"
5
5
7”
Off
Cold
Hot
