INSTALLATION INSTRUCTIONS
FLUSH BOTH SUPPLY LINES BEFORE INSTALLATION
.
AFTER FLUSHING , SHUT OFF BOTH SUPPLY LINES.
SIZE FOR WATER INLET PIPE IS 3/4”
INSTALLATION INSTRUCTION
INSTALLING THE TELESCOPIC POT FILLER ASSEMBLY
1- Insert the rubber washer PM 400 in the groove on the back of the
POT FILLER FLANGE.
WARNING: Where tile construction is planned for the
finished walls, allow for the extra thickness
dimensions when roughing in the valves.
INSTALLING THE VALVE WITH THE TRIM
1- Install the Telescopic Pot Filler assembly onto the wall.
2- Screw in the water inlet pipe in the pot filler assembly.
PAGE 02
3575TX_ _
Water inlet
pipe
1
2
