Santec 3546TD User Manual
3546td, Modena collection, Keep this instruction booklet for future reference
MODENA COLLECTION
KITCHEN FAUCET ASSEMBLY WITH SIDE SPRAY AND WITH “TD” HANDLES
Ш 2.175"
Ш 2.425"
* Please specify the finish when ordering the part.
* Please specify the finish when ordering the part.
KEEP THIS INSTRUCTION BOOKLET FOR FUTURE REFERENCE
PAGE 01
3546TD_ _
ITEM NUMBER
SANTEC
SANTEC
4
4
5
5
SANTEC
SANTEC
9
9
3
3
11
12
13
14
1
7
7
6
6
2
8
8
15
15
8
8
9
9
10
10
16
16
6.5”
8.5”
3.9”
5”
PS-KDOOXA
PM-551
PR-017
P0-419
P0-418
TD-R
TD-L
PM-400
PO-466
PO-467
SM00
HS-2SS
HS 600
Z-200-1
Z-200-2
PR-040
PO-5L1
COMPLETE SPOUT ASSEMBLY, ROMAN TUB FAUCET
CRIMPED METAL WASHER
METAL NUT
HOT CARTRIDGE
COLD CARTRIDGE
COMPLETE “TD” RIGHT HANDLE ASSEMBLY
COMPLETE “TD” LEFT HANDLE ASSEMBLY
RUBBER FLANGE WASHER
“HOT"-HANDLE VALVE SUB-ASSEMBLY
“COLD"-HANDLE VALVE SUB-ASSEMBLY
METAL SIDE SPRAY *
CONNECTING HOSE*
SPRAYER HOLDER MOUNTING HARDWARE
SPRAYER HOLDER FLANGE *
SPRAYER HOLDER GUIDE TUBE*
DIVERTER TEE CONNECTOR
DIVERTER
DESCRIPTION
ITEM
P/N
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
10.75”
