Santec 3529TX User Manual
3529tx, Modena collection, Keep this instruction booklet for future reference
PAGE 01
MODENA COLLECTION
WALL MOUNT WIDESPREAD FAUCET WITH “TX” CROSS HANDLES
##
PART DESCRIPTION
PART #
1
2
3
4
5
6
7
8
Wall Mount Widespread Spout *
Complete TX Cross Handle for Shower *
Hot Cartridge for Left Corner Valve
Regular Adaption Kit for Shower
Cold Cartridge for Right Corner Valve
PS-6D00-U
P0418
PM-3
P0419
* Please specify the finish when ordering the part.
KEEP THIS INSTRUCTION BOOKLET FOR FUTURE REFERENCE
Complete Corner Valve - Left
1
1
3
3
4
4
00YY-TX
SA-Corner-L
5
5
6
6
Complete Corner Valve - Right
SA-Corner-R
7
7
8
8
Allen Key for Set Screws
3529TX _ _-_ _
ITEM NUMBER
9
10
11
Aerator Washer
Aerator Basket with Restrictor
PM-510
PM-320
Aerator Housing *
P0940-U
9
9
10
10
11
11
2
2
2
2
Rubber Washer Flange
PM-400
12
12
12
12
12
3.9”
8.5”
2.175”
3.189”
2.175”
