19
10. Specifications
RocketPort 550 card Specification
Baud rate :
RS 232 (4 RJ45 and Quad) 50 to 460.8K baud
RS 232 (8 RJ11 and Octa) 50 to 115.2K baud
RS 232/422 (8 and 16 Port with interface box) 50 to 230.4K baud
Note : Baud rate is dependant upon hardware and operating system configuration
Bus interface
PCI
Control by device driver
Data bits 7 or 8
Parity Odd, Even or None
Stop bits 1 or 2
Environmental Condition Specification
Air temperature :
System on 0 to 40ºC
System off -20 to 85ºC
Humidity (non-condensing)
System on 8 to 80%
System off 20 to 80%
Altitude 0 to 10,000 feet
MTBF Greater than 30 years
Product 5V Current +12V Current -12V Current
RocketPort 550 4 Quad 210 mA 20 mA 20 mA
RocketPort 550 4 RJ45 190 mA 20 mA 20 mA
RocketPort 550 8 OCTA 140 mA 120 mA 120 mA
RocketPort 550 8 RJ11 250 mA 80 mA 80 mA
RocketPort 550 8 Port 215 mA N/A N/A
RocketPort 550 16 Port 300 mA N/A N/A
