H ANDLE T RIM I NSTALLATION
Step 1
· Unscrew pre-assembled handle trim
from the valve body. Hot valve
assembly “Red” to be mounted on
left. Cold valve assembly “Blue” to
be mounted on right.
Step 3
· Slip valve body up from below tub
deck.
· Reattach pre-assembled handle trim
to the valve body.
Step 2
· Apply a ring of silicone caulking
around the handle hole on deck top.
DO NOT USE PLUMBERS’ PUTTY,
WHICH CAN DAMAGE FINISH.
Step 4
· Align handles with respect to the
spout and tighten bottom lock nut
until secure.
Tub deck
Fiber gasket
Lock nut
INSTALLATION INSTRUCTIONS
PAGE 03
ROMAN TUBS
COLLECTION
SILI CON
E
