Santec 2555XA - Manual

LEAR COLLECTION
ROMAN TUB FILLER WITH HAND HELD SHOWER - “XA” HANDLES
9 9
7 7
5 5
10 10
12 12
13 13
11 11
6 6
4 4
1 1
8 8
14 14
3 3
KEEP THIS INSTRUCTION BOOKLET FOR FUTURE REFERENCE PAGE 01
SANTEC SANTEC
5 5
15 15
16 16
17 17
3 3
3 3
2 2 2 2 2 2
2555XA _ _-_ _
ITEM NUMBER
18 18
19 19
20 20
## PART DESCRIPTION PART #
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Complete Spout Assembly *
Complete XA Cross Handle Assembly *
Flange Washer
Spout Shank Mounting Hardware
Valve Body Mounting Hardware
Hot Cartridge
Cold Cartridge
Complete Hot Valve
Complete Cold Valve
Diverter Cartridge
Diverter Mounting Hardware
Complete Diverter
Hand Shower Mounting Hardware
Guide Tube *
Hand Shower Unit *
PS-5A00S
00XA
PM-400
P0420-SH
P0420-SC
P0495
P0496
P0500R
PM-Z11
Z-200-5
* Please specify the finish when ordering the part.
Hand Shower Flange and Washer *
P0500
Z-200-1
Z-200-2
17 Hand Shower Hose HS-600/HS-700
18 Aerator Washer PM-306
19 Aerator Basket PM-455
20 Aerator Housing * P0952-U
