Santec 2534LA - Manual

PAGE 01
LEAR COLLECTION
PRESSURE BALANCED TUB AND SHOWER WITH “LA” HANDLE
## PART DESCRIPTION PART #
1
2
3
4
5
6
7
Complete Shower head *
Shower Arm *
Complete LA Handle for Shower *
Complete Wall Mount Tub Spout *
P0285
P0286
PS-4A00S
* Please specify the finish when ordering the part.
KEEP THIS INSTRUCTION BOOKLET FOR FUTURE REFERENCE
Shower Flange * P0287
1 1
2 2
3 3
4 4
00YY-LA
PH29750
5 5
H C
6 6
7 7
Tub/shower Trim Plate *
PB-3950 Pressure Balanced Tub/Shower Valve
S
T
8 Allen Key for Set Screw
2534LA _ _-_ _
ITEM NUMBER
8 8
9 9
10 10
11 11
9
10
11
Aerator Washer PM-306
Aerator Basket PM-455
Aerator Housing * P0952-U
12 12 13 13
12
13
Trim Plate Grommet
Diverter Knob * P0258
PM-465
