Santec 2514XA User Manual
2514xa, Keep this instruction booklet for future reference
PAGE 01
LEAR COLLECTION
3-HANDLE TUB/ SHOWER WITH “XA” HANDLES
##
PART DESCRIPTION
PART #
1
2
3
4
5
6
7
8
9
Complete Shower head *
Shower Arm *
Complete XA Handle for Shower *
Complete Wall Mount Tub Spout *
Hot Cartridge for Shower
Regular Adaption Kit for Shower
Diverter Cartridge
Cold Cartridge for Shower
P0285
P0286
P0418
PM-3
P0412
P0419
* Please specify the finish when ordering the part.
KEEP THIS INSTRUCTION BOOKLET FOR FUTURE REFERENCE
10
Complete 3-Handle Tub Shower Valve
P0484
Shower Flange *
P0287
SANTEC
SANTEC
SANTEC
SANTEC
1
1
2
2
3
3
4
4
8
8
6
6
7
7
9
9
10
10
00YY-XA
PS-4A00S
5
5
2514XA _ _-_ _
ITEM NUMBER
11
11
11
Allen Key for Set Screws
12
Aerator Washer
PM-306
13
Aerator Basket without Restrictor
PM-455
14
Aerator Housing *
P0952-U
12
12
13
13
14
14
