Santec 2513XA User Manual
2513xa, Keep this instruction booklet for future reference, Less shower head, arm and flange
PAGE 01
LEAR COLLECTION
3-HANDLE TUB/ SHOWER WITH “XA” HANDLES
##
PART DESCRIPTION
PART #
1
2
3
4
5
6
7
8
9
Complete XA Handle for Shower *
Complete Wall Mount Tub Spout *
Hot Cartridge for Shower
Regular Adaption Kit for Shower
Diverter Cartridge
Cold Cartridge for Shower
P0418
PM-3
P0412
P0419
* Please specify the finish when ordering the part.
KEEP THIS INSTRUCTION BOOKLET FOR FUTURE REFERENCE
10
Complete 3-Handle Tub Shower Valve
P0484
1
1
00YY-XA
PS-4A00S
2513XA _ _-_ _
ITEM NUMBER
11
Allen Key for Set Screws
Aerator Washer
PM-306
Aerator Basket without Restrictor
PM-455
Aerator Housing *
P0952-U
LESS SHOWER HEAD, ARM AND FLANGE
