INSTALLATION INSTRUCTIONS
PAGE 03
AERATOR INSTALLATION
- Insert the Aerator Base with the Washer, Basket and Housing assembled into the
the hole designated for Aerator on the bidet.
- From beneath of the sink, insert the Black Rubber Washer, the Metal Washer
and the Lock Nut. Tighten the Lock Nut firmly against the sink.
- Connect the Aerator Connecting Hose (13) to the Aerator Shank in one side and
connect the other side to the side outlet of the Vacuum Breaker Cartridge.
Tighten firmly both ends to avoid leakage.
- After the connections have been made, turn on the water supply and check for
leakages at all joints. If water leaks from any of the connections tighten the
connection until the leakage stops.
- If no leakage, turn the handles to the full open position and let the water flush for
45 second. This can prevent damages to the ceramic cartridges caused by debris
in the supply line.
Aerator Connecting hose
Aerator Shank Lock Nut
Metal Washer
Black Rubber Washer
Aerator base
Aerator Washer
Aerator Basket
Aerator Housing
INLET HOSE INLET HOSE
SANTEC SANTEC
INLET HOSE INLET HOSE
SA NTE C SA NTE C
1870NX _ _
