Page 441
Cavity Cartridge
Fuse
Mini
Fuse
Description
M16
10 Amp
Red
Airbag Module
M18
15 Amp
Blue
Center Stop Lamp
M19
25 Amp
Natural
Automatic Shutdown
1 and 2
M20
15 Amp
Blue
Instrument Cluster
Interior Lighting /Sw
Steering Wheel/Sw
Bank
M21
20 Amp
Yellow
Automatic Shutdown
3
M22
10 Amp
Red
Horns (Low/High) –
Right
M23
10 Amp
Red
Horns (Low/High) –
Left
Cavity Cartridge
Fuse
Mini
Fuse
Description
M25
20 Amp
Yellow
Fuel Pump Motor/
Diesel Lift Pump – If
Equipped
M26
10 Amp
Red
Driver’s Door Switch
M27
10 Amp
Red
Ignition Switch
M28
15 Amp
Blue
Powertrain Control
Module
M29
10 Amp
Red
Tire Pressure Monitor
M30
15 Amp
Blue
J1962 Diag Connector
M31
20 Amp
Yellow
Back-Up Lamps
M32
10 Amp
Red
Airbag Module
7
MAINTAINING YOUR VEHICLE
439
